Bit Field Diagrams for vr_ad registers

To display a vr_ad registers bit field diagram, you can:

  • hover over a register name (an enum item of vr_ad_reg_kind type) to see it in the tooltip

  • place the cursor on such an element and use the DVT: Show Diagram command

../../_images/bitfield_diagram.gif

Note

Diagrams are rendered using the BitField library.
